SWITCHES AND BOX-MOUNTED THERMOSTATS

SWITCHES AND BOX-MOUNTED THERMOSTATS Product overview and technical data.

eTOUCH BASIC – SWITCH-MOUNTED THERMOSTAT WITH TOUCHPAD

The eTOUCH basic is characterised by its energy saving functionality and shapely design. The fuzzy logic control technology guarantees not only a more constant temperature but also helps to actively save energy. The controller comes with a large colour LCD; a selection function allows you to control either the underfloor or room temperature. Optionally, the room temperature can be regulated and a limit can be set for the floor temperature.

  • Delivery with white frame (gloss)

  • Temperature reduction via external timer

  • Capacitive touch buttons

  • Compatible with various floor sensors

  • Easy menu navigation

  • Protection against overheating of wooden floors

Voltage: 230 V
Current: 16 A
Temperature range: 5 to 40°C
Installation: on flush-mounted switching box
Hysteresis: adjustable +/- 0.2 to 2.0°C
Calibration: -4° to +4°K
Power back-up: 24 hours
Draw-down via external timer
Display colour: White
Frame colour: High-gloss Signal White RAL 9003
Display contrast: 0 to 10
Dimensions: 55 x 55 mm (without frame)
Floor sensor: 3 m (max. 50 m)
IP rating: IP 21
Certification: CE compliant

Compatible frames:



Manufacturer: BERKER

Type: S1 with no intermediate frame

Colour: Polar white / gloss

Fit accuracy: Good



Manufacturer: Busch & Jäger

Type: 1721-1214 Reflex SI Linear spring

Colour: Alpine white

Fit accuracy: Good



Manufacturer: Busch & Jäger

Type: Futur linear & Futur linear central plate

Colour: Studio white

Fit accuracy: Very good



Manufacturer: Jung

Type: LS 98 Duroplast & LS961 Z5 WW Thermoplast central plate

Colour: Alpine white, gloss

Fit accuracy: Very good



Manufacturer: Jung

Type: AS58 WW Duroplast

Colour: Alpine white, gloss

Fit accuracy: Very good



Manufacturer: Jung

Type: AS58 Duroplast

Colour: Gloss white

Fit accuracy: Very good



Non-compatible frames:



Manufacturer: Merten

Type: System M with intermediate frame

Fit accuracy: NO

Manufacturer: Merten

Type: Merten M-Smart

Fit accuracy: NO



Manufacturer: Busch & Jäger

Type: SI Duro 2000

Fit accuracy: NO
